ASMR-270 - Accessories

Home>Products>Stop modules>Stop modules for roller conveyor systems>ASMR-270

Overview accessories ASMR-270 – PDF
https://www.asutec.de/wp-content/uploads/2024/01/zubehoer-asmr-270-1480x910-95.png

No items found

75000060

Fastening set TS 5; B = 455 mm
Consisting of cross strut profile 45x90, 2x bracket 90x90 + fastening accessories
Product request Step-file download

75000059

Fastening set TS 5; B = 650 mm
Consisting of cross strut profile 45x90, 2x bracket 90x90 + fastening accessories
Product request Step-file download

75000054

Fastening set, TS 5; B = 845 mm
Consisting of cross strut profile 45x90, 2x bracket 90x90 + fastening accessories
Product request Step-file download

75000076

Fastening set, TS 5; B = 1040 mm
Consisting of cross strut profile 45x90, 2x bracket 90x90 + fastening accessories
Product request Step-file download

75000077

Fastening set, TS 5; B = 455 mm; Open Center "OC"
Consisting of cross strut profile 90x90, 2x bracket 90x90 + fastening accessories
Product request Step-file download

75000078

Fastening set, TS 5; B = 650 mm; Open Center "OC"
Consisting of cross strut profile 90x90, 2x bracket 90x90 + fastening accessories
Product request Step-file download

75000079

Fastening set, TS 5; B = 1040 mm; Open Center "OC"
Consisting of cross strut profile 90x90, 2x bracket 90x90 + fastening accessories
Product request Step-file download

75000080

Fastening set, TS 5; B = 1040 mm; Open Center "OC"
Consisting of cross strut profile 90x90, 2x bracket 90x90 + fastening accessories
Product request Step-file download

14010008

Push-in L-fitting
G1/8; for tubing outside-Ø6mm
Product request Step-file download

14010020

Push-in fitting (straight)
G1/8; for tubing outside-Ø6mm
Product request Step-file download

14010005

Supply air one way flow valve
G1/8, for tubing outside-Ø6mm
Product request Step-file download

15000004

Size M12x1; (Ø12 x 45 mm); Sn = 4 mm; for flush mounting
Connection: M12x1 connector, 3-pin
Switching output: PNP (NO)
Product request Step-file download

15010001

M12x1 female connector, angled,
LEDs yellow+green, 5-pin, 3-wire,
A-coded, 5 m cable lenght
Product request Step-file download

75009001

Indexing plunger, to lock the stopper in its lowered position.
Suitable for following devices: ASMR-270, ASMR-400 and ASMR-600
Product request Step-file download

75010002

Return stop - retrofittable, suitable for ASMR-270.
Lowering with pivoting movement.
For workpiece carriers with 25 mm stop rigde wideness.
Product request Step-file download

75010003

Return stop - retrofittable, suitable for ASMR-270.
Lowering with pivoting movement.
For workpiece carriers with 40 mm stop rigde wideness.
Product request Step-file download

75010004

Return stop - retrofittable, suitable for ASMR-270.
Lineares Absenken.
For workpiece carriers with 40 mm stop rigde wideness.
Product request Step-file download
Previous page Next page

Back to the base product

ASMR-270
