ASM-15 - Accessories

Home>Products>Stop modules>Stop modules with damping>Stop modules with damping pn>ASM-15

Overview accessories ASM-15 – PDF
https://www.asutec.de/wp-content/uploads/2023/08/zubehoer-asm-15-740x455-95.png

No items found

75000004

Fastening set, consisting of screws, hammer nuts, centering bolts.
For 8 mm profile slot.
Usually for Asutec devices: ASU-70, ASM-15, ASMHS-15, ASMEL-20
Product request Step-file download

14010004

Push-in L-fitting
M5; for tubing outside-Ø6mm
Product request Step-file download

14010009

Push-in fitting (straight)
M5; for tubing outside-Ø6mm
Product request Step-file download

14010006

Supply air one way flow valve
M5, for tubing outside-Ø6mm
Product request Step-file download

15000028

Magnetic field sensor for T-slots; 0,34 m cable
Connection: M8x1 connector, 3-pin
Switching output: PNP (NO)
Product request Step-file download

15000000

For T-slots; 0,3 m cable
Connection: M8x1 connector, 3-pin
Switching output: PNP (NO)
Product request Step-file download

15010000

M8x1 female connector, straight,
3-pin, 3-wire, A-coded,
5 m cable lenght
Product request Step-file download
Previous page Next page

Back to the base product

ASM-15
